5086 Aluminum Plate Sheet

    Alloy 5086 aluminum plate sheet have even higher strength than 5052 or 5083 and its mechanical properties vary significantly with hardening and temperature. It is not strengthened by heat treatment; instead, it becomes stronger due to strain hardening or cold working of the material. This alloy can be readily welded, retaining most of its mechanical strength. The good results with welding and good corrosion properties in seawater make Alloy 5086 aluminum plate sheet extremely popular in marine applications. Alloy 5086 aluminum plate sheet has been used in vehicle armor plate due to its high strength factor.


Principal Design Features
This is a non-heat treatable alloy for strengthening. It has very good corrosion resistance, is easily welded and does have good strength.

Machinability
No specific data. However the alloy is machinable by conventional means.

Forming
Forming characteristics are good for either hot or cold working.

Welding
Weldability of this alloy is very good by conventional means. When filler rod is required it should be the same alloy, 5083.

Forging
Forging may be done in the range of 850 to 750 °F.


Hot Working
Hot forming, when sever deformation is required, may be done at 400 °F or higher to 700 °F.

Cold Working
AL 5083 is readily cold worked by conventional methods. In the annealed (O temper) condition plate of 0.250" thick can be bent on 1.5 T radius.

Annealing
Annealing may be done at 650 F for sufficient time for thorough heating, followed by air cooling.

Tempering
Not applicable.

Hardening
Hardening is accomplished by means of cold working only.

Applications:
Shipyard
Tank cars
Welded and superstructures
Patrol and work boat hulls
Armor plate

    Commonly used in the manufacture of unfired, welded pressure vessels, marine, auto aircraft cryogenics, drilling rigs, TV towers, transportation equipment, and in missile components.


Alloy: 5086
Temper: O, H111, H112, H116, H321,H12,H14, H16, H18, H32, H34, H36
Thickness: 0.2mm--200mm
With: 500mm--2800mm
Length: 1000mm--12000mm
Surface: Mill finish, Bright finish, paper interleaved, one side film, both sides film.

Chemical Properties
Alloy Si Fe Cu Mn Mg Cr Ni Zn Ti Ga V Others Aluminium
min.
Each Total
5086 0.4 0.5 0.1 0.2-0.7 3.5-4.5 0.05-0.25 - 0.25 0.15 - - 0.05 0.15 Remainder
